High Tonnage Round Slings 150,000kg
Features
- Variable load bearing point for more even wear
- Ideal for choke lifting cylindrical objects without creasing
- Less creasing means less wear
- WLL data woven into sleeve for unmistakable capacity identification
- 40% thicker sleeve for durability
- Raised ribs for greater wear and cut resistance
- 20% narrower than standard round slings for easy hook interface
- Lifts smooth objects without damage
- Lightweight and soft – reduced manual handling injuries
- High strength to weight ratio
- Load bearing fibres protected by the outer sleeve
- Wide choice of lifting modes
- Tuff Tag, webbing reinforced encapsulated compliance labels.
Additional information
| Dimensions | N/A |
|---|---|
| Length | 2m, 3m, 4m, 5m, 6m |
| WLL | 10000, 15000, 20000, 25000, 30000, 40000, 50000, 60000, 80000, 100000, 125000, 150000 |
Specifications
| Colour/ Code | Rated WLL (kg) | Thickness Under Load (mm. approx) | Width Under Load (mm. approx) | Minimum load Edge Radius (mm. approx) | Minimum Load Edge Diameter with secutex Sleeve | Maximum Length (metres) |
Maximum Length (metres) |
Weight per Metre |
 MP10000 |
10,000 | 19 | 90 | 57 | N/A | 60 | 1.8 | 2.2 |
| MP15000 |
15,000 | 21 | 115 | 63 | N/A | 60 | 1.8 | 3.2 |
| MP20000 |
20,000 | 23 | 135 | 69 | N/A | 60 | 1.8 | 4.4 |
| MP25000 |
25,000 | 24 | 150 | 72 | N/A | 60 | 1.8 | 5.6 |
| MP30000 |
30,000 | 27 | 170 | 81 | N/A | 60 | 2.0 | 7.4 |
| MP40000 |
40,000 | 37 | 190 | 111 | N/A | 60 | 2.0 | 10.0 |
| MP50000 |
50,000 | 65 | 190 | 195 | N/A | 60 | 2.0 | 13.0 |
| MP60000 |
60,000 | 75 | 220 | 225 | N/A | 60 | 4.0 | 14.8 |
| MP80000 |
80,000 | 86 | 230 | 258 | N/A | 60 | 4.0 | 20.0 |
| MP100000 |
100,000 | 96 | 260 | 288 | N/A | 60 | 4.0 | 26.0 |
| MP125000 |
125,000 | 120 | 325 | 360 | N/A | 60 | 4.0 | 33.8 |
| MP150000 |
150,000 | 144 | 390 | 432 | N/A | 60 | 4.0 | 41.6 |
| Colour/ Code | Rated WLL (kg) |
2 metre | 3 metre | 4 metre | 5 metre | 6 metre | 8 metre |
| MP10000 |
10,000 | MP10000-0x2.0 | MP10000-0x3.0 | MP10000-0x4.0 | MP10000-0x5.0 | MP10000-0x6.0 | MP10000-0x8.0 |
| MP15000 |
15,000 | MP15000-0x2.0 | MP15000-0x3.0 | MP15000-0x4.0 | MP15000-0x5.0 | MP15000-0x6.0 | MP15000-0x8.0 |
| MP20000 |
20,000 | MP20000-0x2.0 | MP20000-0x3.0 | MP20000-0x4.0 | MP20000-0x5.0 | MP20000-0x6.0 | MP20000-0x8.0 |
| MP25000 |
25,000 | MP25000-0x2.0 | MP25000-0x3.0 | MP25000-0x4.0 | MP25000-0x5.0 | MP25000-0x6.0 | MP25000-0x8.0 |
| MP30000 |
30,000 | MP30000-0x2.0 | MP30000-0x3.0 | MP30000-0x4.0 | MP30000-0x5.0 | MP30000-0x6.0 | MP30000-0x8.0 |
| MP40000 |
40,000 | MP40000-0x2.0 | MP40000-0x3.0 | MP40000-0x4.0 | MP40000-0x5.0 | MP40000-0x6.0 | MP40000-0x8.0 |
| MP50000 |
50,000 | MP50000-0x2.0 | MP50000-0x3.0 | MP50000-0x4.0 | MP50000-0x5.0 | MP50000-0x6.0 | MP50000-0x8.0 |
| MP60000 |
60,000 | MP60000-0x2.0 | MP60000-0x3.0 | MP60000-0x4.0 | MP60000-0x5.0 | MP60000-0x6.0 | MP60000-0x8.0 |
| MP80000 |
80,000 | MP80000-0x2.0 | MP80000-0x3.0 | MP80000-0x4.0 | MP80000-0x5.0 | MP80000-0x6.0 | MP80000-0x8.0 |
| MP100000 |
100,000 | MP100000-0x2.0 | MP100000-0x3.0 | MP100000-0x4.0 | MP100000-0x5.0 | MP100000-0x6.0 | MP100000-0x8.0 |
| MP125000 |
125,000 | MP125000-0x2.0 | MP125000-0x3.0 | MP125000-0x4.0 | MP125000-0x5.0 | MP125000-0x6.0 | MP125000-0x8.0 |
| MP150000 |
150,000 | MP150000-0x2.0 | MP150000-0x3.0 | MP150000-0x4.0 | MP150000-0x5.0 | MP150000-0x6.0 | MP150000-0x8.0 |
| Code/ Colour | secutex Code Single Sided | Interior Width (mm) | Exterior Width (mm) | Exterior Height | Weight Per Run Metre |
| MP10000 |
SF1-CS-200 | 180 | 230 | 37 | 3.0 |
| MP15000 |
SF1-CS-250 | 240 | 285 | 35 | 3.1 |
| MP20000 |
SF1-CS-300 | 300 | 330 | 35 | 3.8 |
| MP30000 |
SF1-CS-300 | 300 | 330 | 35 | 3.8 |
| Code/ Colour | secutex Code Single Sided | Interior Width (mm) | Exterior Width (mm) | Exterior Height | Weight Per Run Metre |
| MP10000 |
SF2-CS-200 | 180 | 230 | 37 | 4.2 |
| MP15000 |
SF2-CS-250 | 240 | 265 | 35 | 5.6 |
| MP20000 |
SF2-CS-300 | 300 | 330 | 35 | 6.6 |
| MP30000 |
SF2-CS-300 | 300 | 330 | 35 | 6.6 |
| Code/ Colour | secutex Code Single Sided | Interior Width (mm) | Exterior Width (mm) | Exterior Height | Weight Per Run Metre |
| MP10000 |
SC-CS-180 | 180 | 230 | 37 | 4.1 |
| MP15000 |
SC-CS-240 | 240 | 265 | 35 | 5.0 |
| MP20000 |
SC-CS-300 | 300 | 330 | 35 | 6.4 |
| MP30000 |
SC-CS-300 | 300 | 330 | 35 | 6.4 |
