Load Rollers

Features

Available in capacities varying from 2 to 24 tonne.
Nylon wheels with sealed bearings for increased durability.
Non-slip rubber grip surfaces to prevent load movement.
High visibility colours for safety purposes.

Get A quote

Call Us: 07 3205 7000

Specifications
Applications

Specifications

MODEL	PLR020	PLR040	PLR045	PLR060	PLR065	PLR120	PLR245
Stock Code	PLR020	PLR040	PLR045	PLR060	PLR065	PLR120	PLR245
Rated Capacity per Unit (tonne)	2	4	4	6	6	12	24
Type	Fixed	Fixed	Swivel	Fixed	Swivel	Fixed	Swivel
Plate Size (W x L in mm)	95 x 260	190 x 260	180 x 115	285 x 260	220 x 395	230 x 270	Ø270
Overall Roller Size (mm)	115 x 270 x 110	230 x 270 x 110	250 x 310 x 110	345 x 270 x 110	560 x 395 x 110	400 x 345 x 145	1120 x 415 x 145
Wheels	2	4	4	6	8	8	16
Wheel Size (D x W in mm)	82 x 100	82 x 100	82 x 100	82 x 100	82 x 100	115 x 60	115 x 60

Applications

Designed for moving heavy loads across flat surfaces. The nylon wheels provide added protection to flooring and with the option between swivel or fixed operation, this product is suited for many applications.
