Round Slings up to 8,000kg
Features
- Variable load bearing point for more even wear
- Ideal for choke lifting cylindrical objects
- Lifts smooth objects without damage
- Lightweight and soft
- Reduced manual handling injuries
- High strength to weight ratio
- Load bearing fibres protected by the outer sleeve
- Wide choice of lifting modes
- Tuff Tag, webbing reinforced encapsulated compliance labels
- Certified to AS.4497
Additional information
| Length | 1m, 2m, 3m, 4m, 5m, 6m, 8m |
|---|---|
| WLL | 1000, 2000, 3000, 4000, 5000, 6000, 8000, 10000, 15000, 20000, 30000, 40000, 50000 |
Specifications
| Colour/ Code |
Rated WLL(kg) | Thickness Under Load(mm approx.) | Width Under Load (mm approx.) | Minimum Load Edge Radius (mm) | Minimum Load Edge Diametre with Secutex Sleeve | Maximum Length (metres) | Minimum Length (metres) | Weight per Metre (kg) |
 E1000 |
1000 | 6 | 45 | 18 | N/A | 60 | 0.5 | 0.3 |
 E2000 |
2000 | 7 | 48 | 21 | N/A | 60 | 0.5 | 0.5 |
 E3000 |
3000 | 8 | 60 | 24 | N/A | 60 | 0.5 | 0.80 |
 E4000 |
4000 | 10 | 65 | 30 | N/A | 60 | 1.0 | 1.00 |
 E5000 |
5000 | 10 | 75 | 30 | N/A | 60 | 1.0 | 1.20 |
 E6000 |
6000 | 13 | 80 | 39 | N/A | 60 | 1.0 | 1.40 |
 E8000 |
8000 | 15 | 80 | 45 | N/A | 60 | 1.0 | 1.80 |
| Colour/Code | Rated WLL(kg) | 1 Metre | 2 Metre | 3 Metre | 4 Metre | 5 Metre | 6 Metre | 8 Metre |
| E1000 |
1000 | E1000-0x1.0 | E1000-0x2.0 | E1000-0x3.0 | E1000-0x4.0 | E1000-0x5.0 | E1000-0x6.0 | E1000-0x8.0 |
| E2000 |
2000 | E2000-0x1.0 | E2000-0x2.0 | E2000-0x3.0 | E2000-0x4.0 | E2000-0x5.0 | E2000-0x6.0 | E2000-0x8.0 |
| E3000 |
3000 | E3000-0x1.0 | E3000-0x2.0 | E3000-0x3.0 | E3000-0x4.0 | E3000-0x5.0 | E3000-0x6.0 | E3000-0x8.0 |
| E4000 |
4000 | E4000-0x1.0 | E4000-0x2.0 | E4000-0x3.0 | E4000-0x4.0 | E4000-0x5.0 | E4000-0x6.0 | E4000-0x8.0 |
| E5000 |
5000 | E5000-0x1.0 | E5000-0x2.0 | E5000-0x3.0 | E5000-0x4.0 | E5000-0x5.0 | E5000-0x6.0 | E5000-0x8.0 |
| E6000 |
6000 | E6000-0x1.0 | E6000-0x2.0 | E6000-0x3.0 | E6000-0x4.0 | E6000-0x5.0 | E6000-0x6.0 | E6000-0x8.0 |
| E8000 |
8000 | E8000-0x1.0 | E8000-0x2.0 | E8000-0x3.0 | E8000-0x4.0 | E8000-0x5.0 | E8000-0x6.0 | E8000-0x8.0 |
 E10000 |
10000 | E10000-0x1.0 | E10000-0x2.0 | E10000-0x3.0 | E10000-0x4.0 | E10000-0x5.0 | E10000-0x6.0 | E10000-0x8.0 |
| E15000 |
15000 | E15000-0x1.0 | E15000-0x2.0 | E15000-0x3.0 | E15000-0x4.0 | E15000-0x5.0 | E15000-0x6.0 | E15000-0x8.0 |
| E20000 |
20000 | E20000-0x1.0 | E20000-0x2.0 | E20000-0x3.0 | E20000-0x4.0 | E20000-0x5.0 | E20000-0x6.0 | E20000-0x8.0 |
| E30000 |
30000 | E30000-0x1.0 | E30000-0x2.0 | E30000-0x3.0 | E30000-0x4.0 | E30000-0x5.0 | E30000-0x6.0 | E30000-0x8.0 |
| E40000 |
40000 | E40000-0x1.0 | E40000-0x2.0 | E40000-0x3.0 | E40000-0x4.0 | E40000-0x5.0 | E40000-0x6.0 | E40000-0x8.0 |
| E50000 |
50000 | E50000-0x1.0 | E50000-0x2.0 | E50000-0x3.0 | E50000-0x4.0 | E50000-0x5.0 | E50000-0x6.0 | E50000-0x8.0 |
| Colour/ Code | secutex Code Single Sided | Interior Width | Exterior Width | Exterior Height | Weight Per Run Metre |
| E1000 |
SFI-50 | 50 | 70 | 22 | 0.9 |
| E2000 |
SFI-75 | 75 | 95 | 22 | 1.3 |
| E3000 |
SFI-100 | 100 | 120 | 22 | 1.5 |
| E4000 |
SFI-140 | 140 | 160 | 22 | 2.1 |
| E5000 |
SFI-150 | 150 | 170 | 22 | 2.1 |
| E6000 |
SFI-180 | 180 | 200 | 35 | 2.7 |
| E8000 |
SFI-240 | 240 | 260 | 35 | 3.2 |
| Colour/ Code | secutex Code Single Sided | Interior Width | Exterior Width | Exterior Height | Weight Per Run Metre |
| E1000 |
SF2-50 | 50 | 70 | 70 | 1.2 |
| E2000 |
SF2-75 | 75 | 95 | 95 | 1.8 |
| E3000 |
SF2-100 | 100 | 120 | 120 | 2.1 |
| E4000 |
SF2-140 | 140 | 160 | 160 | 3.0 |
| E5000 |
SF2-150 | 150 | 170 | 170 | 3.0 |
| E6000 |
SF2-180 | 180 | 200 | 35 | 3.3 |
| E8000 |
SF2-240 | 240 | 260 | 35 | 4.2 |
| Colour/ Code | secutex Code Single Sided | Interior Width | Exterior Width | Exterior Height | Weight Per Run Metre |
| E1000 |
SC-50 | 50 | 70 | 70 | 1.1 |
| E2000 |
SC-75 | 75 | 95 | 95 | 1.6 |
| E3000 |
SC-100 | 100 | 120 | 120 | 1.8 |
| E4000 |
SC-140 | 140 | 160 | 160 | 2.6 |
| E5000 |
SC-150 | 150 | 170 | 170 | 2.6 |
| E6000 |
SC-180 | 180 | 200 | 35 | 3.3 |
| E8000 |
SC-240 | 240 | 260 | 35 | 4.2 |
